. Performance Model Task 500W Article no. TPS-500S EAN code 0753263076489 Weight (without/with package) 1.62 kg / 2.03 kg AC Input 100-240V / 8.0A Frequency 47-63Hz +5V 16A +3,3V 18A +5V & +3,3V combined 100W +12V 1 456W / 38A +12V 2 - +12V 1 & +12V 2 combined - P.F. >0,9 -12V 0,3A / 3,6W +5VsB 2,5A / 12,5W Maximum Power 500W Connectors 24PIN ATX 1 8 PIN EPS (4+4) 1 8 PIN PCIe (6+2) 1 SATA 5 MOLEX 3 Cable length 24PIN ATX 650 8 PIN EPS (4+4) 650 8 PIN PCIe (6+2) 500 SATA/MOLEX/MOLEX 500/150/150 MOLEX/SATA/SATA 500/150/150 SATA 500/150 Features Specification ATX 12V 2.3 Form factor PS II Efficiency 80 PLUS® Bronze Dimension (DxWxH) 140 mm x 150 mm x 87 mm PFC Active PFC (0.9) Fan 120mm silent fan Security AFC (Automatic Fanspeed Control) OPP (Overload Protection) OTP (Over Temperature Protection) OVP (Overvoltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Undervoltage Protection)
